650W |
Server,Workstation,Storage System,IPC |
|
| |
|
|
|
|
330.00x101.20x84.00 (mm)
12.90x3.98x3.31 (inch) |
|
VOLTAGE: 90~264VAC FULL RANGE
FREQUENCY: 47~63HZ
INPUT CURRENT: 5A (RMS) FOR 230VAC
10A (RMS) FOR 115VAC
INRUSH CURRENT: 40A MAX.FOR 115 VAC PER MODULE
60A MAX. FOR 230 VAC PER MODULE |
|
|
|
Output Voltage |
Output Current Min. |
Output Current Max. |
Output Current Peak |
Regulation Load |
Regulation Line |
Output Ripple & Noise Max.[P-P] |
+5V |
1.0 |
32.00 |
|
± 5% |
± 1% |
50mV |
| +12V |
2.0 |
45 |
|
± 5% |
± 1% |
120mV |
-12V |
0 |
1.00 |
|
± 5% |
± 1% |
120mV |
+3.3V |
1.0 |
25.00 |
|
± 5% |
± 1% |
50mV |
+5VSB |
0.1 |
3.00 |
|
± 5% |
± 1% |
50mV |
|
|
|
* TEMPERATURE RANGE: OPERATING 0℃ --- 45℃,STORAGE -40℃ --- 70℃
* HOLD UP TIME: 16 ms MINIMUM AT FULL LOAD & 90VAC INPUT VOLTAGE
* EFFICIENCY: 70% TYPICAL AT 115VAC, FULL LOAD
* POWER GOOD SIGNAL: ON DELAY 100 ms TO 500 ms, OFF DELAY 1 ms
* OVER POWER PROTECTION
* OVER VOLTAGE PROTECTION
* OVER CURRENT PROTECTION
* SHORT CIRCUIT PROTECTION
* EMI NOISE FILTER: FCC CLASS B, CISPR22 CLASS B
* FAULTY ALARM METHODS: LED, BUZZER, TTL SIGNAL
* WARNING METHOD: AUDIO ALARM, POWER DETECTIVE SIGNAL DELIVERY
* REMOTE SENSING DESIGN
* ISOLATION: BUILT-IN THE POWER MODULE |
|
